Product details
【Product Applicable Model】
- BMW 4 Pin Rear Lens SONY Lens 1080P 1920 x1080 (JD-03AL)
Applicable:: Jinpei JD-07B、JD-11BS、JD-14B、JD-15BS
- BMW 5 Pin rear lens 720P 1280 x 720 (JD-02AL)
Applicable: Jinpei JD-05B
-- BMW 5 Pin rear lens 720P 1280 x 720 (JD-01AL)
Applicable: Jinpei JD-01B、JD-04B、JD-10B、JD-09、JD-13B。
-------------------------------------------
【Product Specifications】
High-quality streaming mirror core lens
Suitable for most electronic mirrors, noise at night is minimal
Effectively suppress the light line of the rear vehicle
Model: JD-02AL
Shooting angle: 120 degrees horizontal
Signal processing: AHD signal, 25/PAL
Resolution: AHD 1080P(1920*1080)
Light lens lens: 6 glass high penetration lens
Aperture: F1.6
Sensor: SONY IMX307 1/"2.8CMOS
Sensor Size: 1/2.8"
Minimum illumination: 0.01Lux
Format: PAL/25 (speed 25.00 pictures/sec.)
Appearance material: all-alloy shell (strong heat dissipation)
【Using high image processing FH series ISP processor】
➡ Strong light suppression (to avoid glare caused by rear headlights).
➡ Two-frame synthetic WDR mode
➡ High-performance CFA interpolation
➡ Automatic 2D and Y/C denoising
➡ High-performance 3D denoising
➡ Auto Exposure/Auto White Balance/AF Statistics
➡ Vignetting compensation
➡ Dead pixels are automatically detected and eliminated
➡ Motion detection and area masking
▲Lens size▲
Width 40mm, length 31mm, height 25mm
Weight 66g
【Product contents】
Streaming Lens X1 (4PIN BMW connector)
6m BMW head back pull cable
3M fixed film
Screw X2
Lens protector X1
